COD: DMTO008A - EAN: 8056095440803
If you need more information on this product write us here (without any commitment) and specify your interest
Instead, use this link to request the new damatomacchine product catalog for free with all our machine tools
List price :15.587,00 € - PROMO: 11.990,00 € (VAT Included)
Product: Available - Product Condition: New
Terms of sale - Returns and Refunds Policy
DESCRIPTION
Robust and precise, this lathe can be used in various mechanical workshops for threading and to reproduce metallic elements of extreme precision.
Zoom Images
Professional Lathe Titanius 1000 Dro
Professional Lathe Titanius 1000 Dro
Professional Lathe Titanius 1000 Dro
Professional Lathe Titanius 1000 Dro
Professional Lathe Titanius 1000 Dro
Professional Lathe Titanius 1000 Dro
Shipping costs for Ireland: 792,00 € (VAT Included)
We ship worldwide, for any information concerning the shipping costs in your country (as well as for billing, merchandise returns or other) write us through this web page or if you prefer, call us directly to our phone numbers
Technical data | WEIGHT & MEASURES |
| Packing case dimension | 2060 mm (lenght) x 900 mm (width) x 1320 mm (height) |
| Dimensions with stand | 1940 mm (lenght) x 850 mm (width) x 1320 mm (height) |
| Net weight | 1350 Kg |
| Cross weight | 1555 Kg |
| METAL LATHE CAPACITY | |
| Distance between center | 40" (1000 mm) |
| Swing over bed | 16"(410 mm) |
| Swing over cross slide | 10"(255 mm) |
| Centre height | 8"(205 mm) |
| Spindle Diameter | 200mm |
| Cutting tool max section | 190" x 190" (20 mm x 200 mm) |
| Total travel of cross slide | 189" (210 mm) |
| HEADSTOCK | |
| Spindle bore | 2" (52 mm) |
| Spindle speeds range | 45 - 1800 rpm |
| Spindle Diameter | 200mm |
| Spindle speeds number | 16 |
| Spindle Nose | D1-6 |
| Spindle morse taper in bore | MT 6 |
| THREAD & FEEDS | |
| Leadsrew diameter & thread | 28 mm x 6 mm or 4TP |
| Cross feeds imperial | 0.001 - 0.0335 / Rev (17Nos) |
| Cross feeds metric/td> | 0.025 mm - 0.85 mm / Rev (17Nos) |
| Threads Imperial Pitches | 2 - 72 T.P.I. (45 Nos) |
| Threads Metric Pitches | 0.2 - 14 mm (39 Nos) |
| Longitudinal Feeds Imperial | 0.002 - 0.067 / Rev (17 Nos) |
| LATHE MOTOR | |
| Power | Double winding 2.2kW and 3.3kw |
| Type | Three-phase |
| COOLING PUMP | |
| Power | 90 W |
| Type | Three-phase |
| FEED | |
| Longitudnal Feed | Automatic in both direction |
| Cross Feed | Automatic in both direction |
Accessories Available for Professional Lathe Titanius 1000 Dro
Anti-vibration feet kit for lathes
Kit of 6 anti-vibration feet for metal lathes of the Multitech 1000 and Titanius series
(Cod: DMRI1717)
- 181,00 € ( VAT included )
Faceplate Ø 350 mm
(Cod: DMACTF183)
- 195,00 € ( VAT included )
Rotary tailstock lathe - Taper CM4
(Cod: DMACTF179)
- 59,00 € ( VAT included )
Live center chuck - Taper MT4
(Cod: DMACTF178)
- 45,00 € ( VAT included )
4 Jaw Independent Lathe Chuck
Lathe chuck with 4 independent jaws diameter 250 mm
(Cod: DMACTF626)
- 387,00 € ( VAT included )
tool kit with interchangeable inserts 20 mm
tool kit with interchangeable inserts 20 mm
(Cod: DMACTF106)
- 196,00 € ( VAT included )
Spindle with 4 self-centering pliers Ø 250 mm
Spindle with 4 self-centering pliers Ø 250 mm
(Cod: DMACTF1000)
- 732,00 € ( VAT included )
4 Jaw Independent Lathe Chuck
Lathe chuck with 4 independent jaws diameter 250 mm
(Cod: DMACTF626)
- 387,00 € ( VAT included )
Spindle with 4 self-centering pliers Ø 250 mm
Spindle with 4 self-centering pliers Ø 250 mm
(Cod: DMACTF1000)
- 732,00 € ( VAT included )
Quick change turret model T00E
With 4 interchangeable tool holders, maximum mountable size 20 mm
(Cod: DMACTF60)
- 533,00 € ( VAT included )
